Aja OG-FIDO-R-MM openGear 1-Channel Multi-Mode LC Fiber to 3G-SDI Rece
ngshop.co.
0
Currency
Aja OG-FIDO-R-MM openGear 1-Channel Multi-Mode LC Fiber to 3G-SDI Rece

Aja OG-FIDO-R-MM openGear 1-Channel Multi-Mode LC Fiber to 3G-SDI Rece

$905.00
Tags:
1-Channel Multi-Mode LC Fiber to 3G-SDI Receiver, DashBoard Support The OG-FiDO-R-MM offers unmatched flexibility and cost efficiency for 3G-SDI Fiber conversion, allowing for cable runs up to 700 m (2296 ft) for OM4 and 300 m (984 ft) for OM3 for Multi-Mode fiber optic cables - useful for eliminating ground loop problems.
Quantity
Add to Cart
Product Details
SPECIFICATION

Video Formats

150 Mbps - 3 Gbps, format agnostic



Video Input Digital

1-Channel Multi-Mode LC Fiber Input, SMPTE-297

Nominal Wavelength: 850 nm

Optical Sensitivity: -15dBm (min)

Video Output Digital

1-Channel Dual matching 3G-SDI BNC Outputs, SMPTE-259/292/424

Reclocking

270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select

All other rates are passed through and not reclocked



User Interface

openGear DashBoard network control software via Windows, macOS or Linux



Size (w x d x h)

openGear standard form factor, front slot and rear card. Two slots required for each card.



Weight

0.5 lb (0.3 kg)



Power

openGear frame compatible, 2.5 watts max per card



Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)

Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)

Operating Relative Humidity: 10-90% noncondensing

Operating Altitude: <3,000 meters (<10,000 feet)
