Inputs | 1 x 3G/HD/SD-SDI
1 x HDMI
1 x VGA
2 x RCA (unbalanced audio L/R)
1 x reference input |
Outputs | 1 x 3G/HD/SD-SDI
1 x HDMI |
Firmware Updates | 1 x mini-USB |
Power Input | DC jack |
Supported Video Input Formats | SDI (YUV)
1080p60/59.94/50
1080p30/29.97/25/24/23.98
1080psf30/29.97/25/24/23.98
1080i60/59.94/50
720p60/59.94/50
625i
525i
HDMI (YUV / RGB)
3840 x 2160p60/59.94/50
3840 x 2160p30/29.97/25/24/23.98
1080p60/59.94/50
1080p30/29.97/25/24/23.98
1080psf30/29.97/25/24/23.98
1080i60/59.94/50
720p60/59.94/50
480p, 576p, 480i, 576i
1600 x 1200 at 60 Hz
1400 x 1050 at 60 Hz
1366 x 768 at 60 Hz
1280 x 1024 at 60 Hz
1024 x 768 at 60 Hz
800 x 600 at 60 Hz
VGA (RGB)
1920 x 1080 at 60 Hz
1600 x 1200 at 60 Hz
1400 x 1050 at 60 Hz
1366 x 768 at 60 Hz
1280 x 1024 at 60 Hz
1280 x 720 at 60 Hz
1024 x 768 at 60 Hz
800 x 600 at 60 Hz |
Supported Video Output Formats | SDI (YUV)
1080p60/59.94/50
1080p30/29.97/25/24/23.98
1080i60/59.94/50
720p60/59.94/50
625i
525i
HDMI (YUV)
3840 x 2160p60/59.94/50
3840 x 2160p30/29.97/25/24/23.98
1080p60/59.94/50
1080p30/29.97/25/24/23.98
1080i60/59.94/50
720p60/59.94/50
576p
480p
576i
480i |
Video Processing | SDI: YUV 4:2:2
HDMI: YUV 4:2:2, YUV 4:4:4, RGB 4:4:4, YUV 4:2:0 (4K only) |
Supported Audio Input Formats | Unbalanced Audio L/R: Stereo audio
SDI Embedded Audio: Up to 8-ch, 48 kHz, PCM audio
HDMI Embedded Audio: Up to 8-ch, 44.1/48/96 kHz, PCM audio |
Supported Audio Output Formats | SDI Embedded Audio: Up to 8-ch, 48 kHz, PCM audio
HDMI Embedded Audio: Up to 8-ch, 48 kHz, PCM audio |
Frame Delay | I: 2-3 fields
P: 0-1 frames |
Power Supply | 12 VDC, 1 A (9.4 W) |
Operating Temperature | 32 to 104°F (0 to 40°C) |
Humidity | 10 to 80% |
Certification | CE, FCC |
Dimensions | 8.6 x 5.5 x 1.6" (22 x 14 x 4 cm) |
Weight | 2.2 lb (1 kg) |
