Aja OG-3GDA-2X4 openGear 2x4 3G-SDI reclocking DA

Video Formats

150 Mbps - 3 Gbps, format agnostic

Video Input Digital

1x 3G-SDI BNC (1x8 mode), SMPTE-259/292/424

2x 3G-SDI BNC (2x4 mode), SMPTE-259/292/424

Video Output Digital

8x 3G-SDI BNC, SMPTE-259/292/424

4x outputs noninverting (1x8 mode)

2x outputs noninverting for each DA (2x4 mode)

Cable Equalization

(Belden 1694A coax)

270 Mbps, 350m

1.5 Gbps, 200m

3 Gbps, 120m

Reclocking

270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select

All other rates are passed through and not reclocked

User Controls

openGear DashBoard network control software via Windows, macOS or Linux

Size (w x d x h)

openGear standard form-factor, front slot and rear card

Slots: Two slots required for each card

Weight

0.5 lb (0.3 kg)

Power

openGear frame compatible, 2.6 watts max per card

Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)

Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)

Operating Relative Humidity: 10-90% noncondensing

Operating Altitude: <3,000 meters (<10,000 feet)
