Aja OG-FIDO-R 1-Channel Single Mode LC Fiber to 3G-SDI Receiver

Video Formats

150 Mbps - 3 Gbps, format agnostic

Video Input Digital

1-channel Single Mode LC Fiber Input, SMPTE-297

Nominal Wavelength: 1260 - 1620 nm

Optical Sensitivity: -18dBm (min)

Overload Power: -3dBm (min)

Video Output Digital

1-channel Dual matching 3G-SDI BNC Outputs, SMPTE-259/292/424

Reclocking

270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select

All other rates are passed through and not reclocked

Size (w x d x h)

4.6" x 1.71 " x.85" (117 x 43.5 x 21.6mm)

Weight

0.5 lb (0.3 kg)

Power

2 watts max

Uses 5-20VDC power (AJA power supply model DWP-U-R1 included)

Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)

Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)

Operating Relative Humidity: 10-90% noncondensing

Operating Altitude: <3,000 meters (<10,000 feet)
