Aja OG-FIDO-R-12G-S 1-Channel 12G-SDI/ST Single Mode ST Fiber Receiver

Video Formats

270Mbps - 12 Gbps, format agnostic

Video Input Digital

1-channel Single Mode ST Fiber connector, SMPTE 297/259/292/424/2081/2082

Nominal Wavelength: 1260 nm (min), 1620 nm (max)

Optical Sensitivity:

-10 dBm (max 6 and 12 Gbps)

-14 dBm (max 270 Mbps, 1.5 Gbps and 3 Gbps)

Overload Power: -2 dBm (min)

Video Output Digital

1-channel dual matching 12G-SDI BNC connectors, SMPTE 259/292/424/2081/2082

Reclocking

270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.967 Gbps, 2.970 Gbps, 5.934 Gbps, 5.940 Gbps, 11.868 Gbps, 11.880 Gbps - Auto Select

All other rates are passed through and not reclocked

User Interface

openGear DashBoard network control software via Windows, macOS or Linux

Size

openGear standard form factor, front slot and rear card. Two slots required for each card

Weight

0.5 lb (0.3 kg)

Power

openGear frame compatible, 3 watts max per card

Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)

Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)

Operating Relative Humidity: 10-90% non-condensing

Operating Altitude: <3,000 meters (<10,000 feet)
