DATAVIDEO HS-1300 6-Channel HD Portable Video Streaming Studio

Video Standard

HD

Video Format

1080i 50/59.94/60Hz
720p 50/59.94/60Hz

Input Routable / Crosspoint

All 6, repeatable

Video Input

4 x HD-SDI
2 x HDMI

Computer Graphic Interface

2 via HDMI

Down-converted Output

N/A

Video Output

3x HDMI

2x SDI assignable: AUX 1-6, PGM, PVW, PGM Clean or Multiview

Audio Input

2x Balanced XLR

Audio Output

1x Stereo headphone

Digital Embedded Audio Support Input

Input 2 channels, Output 2 channels

A+V Switching

Yes

USK

2x USK support Chromakey

DSK

2, support Lumakey & Linear key (Key / Fill)

Picture in Picture

1

Logo Insertion

N/A

Built-in Audio Mixer

N/A

Built-in Monitor Display

17.3” HD TFT LED backlit, 1600x900 pix

Built-in Intercom & Tally

N/A

Streaming Video Encode

H.264 / AVC, Main/ High Profile
Configurable Bit-rate up to 10Mbps

Streaming Audio Encode

AAC-LC
Configurable bit rate range from 32Kbps to 384Kbps
Sample rate: 48KHz, 16bit

Streaming Protocol

TS over TCP/UDP (unicast & multicast)
RTSP over HTTP/TCP/UDP
RTMP/RTMPS (Publish)

Streaming Control

Web browser UI for configuration and control Socket commands

Recording File System

FAT, exFAT, NTFS

Recording File Format

MP4

Recording Setting Control

Web UI for system configuration and control

Special Features

Streaming encoder and recorder
2 chromakey virtual studio
9 stinger transition and 30 virtual sets included

Dimension (LxWxH)

455 x 355 x 134 mm

Weight

16.3 Lbs (7.4 kg), Reinforce Plastic Case

Power

DC 12V, 5A

Operating Temp. Range

0~40 °C

Options

CB-22H/23H/46/47/60/61/62

What's in the Box

Content

1 x HS-1300 Product
1 x AD Switch DC 12V with AC Cord
1 x Thank You Card
