General
Power Requirements DC12 V (11–17.0 V)
Power Consumption With LCD ScreenUnit nominal power consumption: Approx. 50.0 W (lens, 6K 17:9, 59.94P, X- OCN LT recording, auto fan, excluding grip remote control and peripheral devices)
Unit maximum power consumption: Approx. 66.0 W (lens, 6K 17:9, 59.94P, X-OCN LT recording, 40 °C (104 °F) environment, ND filter (1/4), proxy recording on, Wi-Fi on, auto fan, including grip remote control and peripheral devices))
Operating Temperature 0°C ～ 40°C
Storage Temperature -20°C-60°C
Mass Approx. 2.4 kg / 5 LB 4.7 oz (body only, excluding PL-mount adapter)
(without lens, handle, VF attachment and accessories)
Dimensions: 145.7 x 142.5 x 218.1 mm (WxHxD excluding protrusions)
Camera
Imaging Device 35 mm full frame (35.9 x 24.0 mm), Exmor RS CMOS image sensor
Imaging Device Pixel Count 41.9 M (total)
Built-In ND Filters CLEAR, linear variable ND (0.6(1/4) - 2.1(1/128))
ISO Sensitivity ISO 800/3200 (Cine EI mode, D55 Light source)
Lens Mount PL Mount (detachable)/E-mount (lever lock type)
Latitude 16 Stop
Recording
X-OCN(LT), XAVC H Intra HQ, XAVC H Intra SQ, XAVC H Long, XAVC Intra, XAVC Long
Recording Format (Audio)
LPCM 4ch, 24-bit 48-kHz
PC interface Mass-storage
USB Type-C® Terminal
Yes (SuperSpeed USB 5 Gbps (USB 3.2) compatible)
Wireless LAN (built-in)
Yes (Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac (2.4 GHz band/5 GHz band))*2*3
HDMI output
HDMI connector (Type-A)
XLR audio input
Yes (3-pin (female) x2)
Headphone terminal
Yes (3.5 mm Stereo mini jack)
Remote terminal
2.5 mm, 3-pole sub-mini type
SDI output
SDI OUT1: BNC, 12G-SDI, 6G-SDI, 3G-SDI (Level A/B), HD-SDI
SDI OUT2: BNC, 3G-SDI (Level A/B), HD-SDI
DC input
XLR, 11 V to 17 V
TC input/TC output
BNC, TC IN/OUT Switchable
Genlock input/Ref output
BNC, REF IN/OUT Switchable
Grip remote control connector
3.5 mm, 4-pole mini jack
LAN terminal
Yes (1000BASE-T, 100BASE-TX, 10BASE-T)
Microphone
Built-in, monaural
SpeakerBuilt-in, monaural
This product contains pre-installed software and requires the purchase of license keys to activate some functions.
