Swit PB-S146A/S Multi-sockets Square Cine Battery
PB-S146A provides at least 200W/16A high load even at 1% capacity, to drive high power Cine cam- eras and on-camera devices together. The high load cells will also ensure battery life comparing to normal load batteries if long time full load output.
Battery plate | Gold-mount |
Nominal voltage | 14.4V |
Capacity | 146Wh, 10.1Ah |
Max output | In total: 200W |
Electrodes: 200W,16A | |
USB:10W, 5V/2A | |
D-tap: 120W / 10A | |
Dimension | 121×95×59mm |
Charging Temperature | 0-40°C |
Discharging Temperature | -20°C-50°C(Capacity and Max Load may decrease when operating below 0°) |
Net weight | 0.878kg |
Max charging current | 5A |
D-TAP socket number | 2 |
USB socket number | 1 |
