Swit KA-R31B B-mount Hotswap Plate for MINI / MINI LF
$1,044.00
Tags:
KA-R31B is a B-mount hot-swap plate for ARRI Alexa MINI / MINI LF install with SDI 1 in 2 out distribution and isolater, power cameras at 28.8V (22-33.6V) by 8-pin DC-IN.
Product Details
SPECIFICATION
Inner battery voltage | 28V regulated |
Inner battery capacity | 32Wh/3Ah |
Power load | 200W constant high load |
8-pin LEMO output | Attach battery: 22-33.6V to camera Remove battery: 28V / 200W to camera |
D-tap output x2 | 14V regulated, 70W |
2-pin LEMO output | 14V regulated, 70W |
USB-A output | 5V, 10W/2A |
8-pin LEMO input | 22-33.6V |
BNC x1 | 3G/HD/SD-SDI input |
BNC x2 | 3G/HD/SD-SDI distribution output |
Dimensions | 93×143×54.4mm |
Net weight | Net 818.5g; With package1kg |
