Blackmagic Design Cloud Pod
Connections
10Gb Ethernet Ports | 1 x RJ45 Port Supports 100/1000/10G BASE-T |
USB Type-C | 2 x 5 Gb/s USB 3.0 Type-C Ports for External Storage |
HDMI Monitor Outputs | 1 |
Computer Interface | Ethernet for Shared File Access, Configuration, and Software Updates USB Type-C for Configuration and Software Updates |
File Sharing Protocol
Protocol | SMB |
Computer Connections | 50 Max |
Cloud Synchronization
Compatible Services | Dropbox |
Storage
Storage Type | Bring Your Own Drive |
External Storage | USB Disks |
External Storage Format | ExFAT (Windows/Mac) or HFS+ (Mac) File Systems |
Displays
HDMI Monitor Outputs | 1080p50, 1080p59.94, and 1080p60 |
Monitor Out Displays | Device Name, Storage Capacity and Use, Cloud Sync Status, User Activity, Hardware Status, Storage Map, and Network Data Rate Graphs |
Status Indicator | Glow Strip Illuminates Red During Read or Write Operations |
Device Control
External Control | USB Type-C or Ethernet for Configuration and Software Updates |
Software
Software Included | Blackmagic Cloud Setup Utility Blackmagic Proxy Generator Lite Internal Software Upgrade via Blackmagic Cloud Setup Using the USB Type-C Port |
Operating Systems
Mac | macOS 11.1 Big Sur, 12.0 Monterey, and later |
Windows | Windows 10 and 11 |
Power Requirements
Power Supply | 1 x External 12 VDC 60 W Power Supply |
Power Input | 1 x 12 VDC Locking 5.5 mm Barrel Connector |
Power Usage | 25 W without External USB Disks |
Environmental Specifications
Operating Temperature | 32 to 104°F / 0 to 40°C |
Storage Temperature | -4 to 140°F / -20 to 60°C |
Relative Humidity | 0 to 90% Non-Condensing |
Physical Specifications
Dimensions | 6.35 x 5.00 x 1.00" / 16.1 x 12.7 x 2.54 cm |
Weight | 1.0 lb / 0.5 kg |
