Vinten 16x4 3G/HD/SD-SDI switcher, serial and Ethernet control

Video Formats

270 Mb/s, 1.5 Gb/s, 3 Gb/s SDI, SMPTE-259/292/424
270 Mb/s DVB-ASI
Format agnostic, 10 Mb/s to 3 Gb/s

Video Input Digital

16 x 3G-SDI, BNC

Video Output Digital

4 x 3G-SDI, BNC
Non-inverting

Cable Equalization

3 Gb/s, up to 459' / 140 m, using Belden 1694A
1.5 Gb/s, up to 656' / 200 m, using Belden 1694A
270 Mb/s, up to 1312' / 400 m, using Belden 1694A
Automatic operation

Reclocking

270 Mb/s, 1.483 Gb/s, 1,485 Gb/s, 2.966 Gb/s, 2.970 Gb/s
Automatic rate selection
Automatic reclocker bypass

Switching

Single-, dual-, and quad-link modes
Switches in vertical blanking per SMPTE RP-168

Reference Input

2 x BNC, external
Looping, non-terminating
Blackburst or tri-level sync

Network Interface

1 x RJ45, 10/100/1000 Ethernet
Supports AJA KUMO Ethernet control panels (direct connect or networked)
Grass Valley Native Protocol
Embedded web server for remote control

Serial Interface

1 x DB-9, RS-422, female
Grass Valley Native Protocol
9-pin, D-connector pinout

Power

9-17 VDC regulated, 7 W typical, 9.6 W maximum
AC Adapter: 100-240 VAC, 50/60 Hz, universal input

Dimensions

17.4 x 1.5 x 1.8" / 48.3 x 3.9 x 4.5 cm
1 RU

Weight

1.2 lb / 0.54 kg
