Harmonic MCX-7000 Newtec Modulators, Per Unit: Dual PSU, IP Input , L-band output, DVB-S/S2/S2X ,QPSK/8PSK , S.Rate= 15 Mbaud
$17,200.00
Tags:
MCX7-CH-05 Hardware Platform: Chassis Type 05 (7000). Includes one MCX7-MS-20 Operating Software: MCX7000 Major Software R2.0 1 MCX7-VP-01 Data/Video Package: Video TS, Carrier-ID(NIT), TS Analyser 1 MCX7-DL-00 No demodulator board license 1 MCX7-PS-01 Mains Power Supply Unit: PSU Dual Redundant AC 110/240V 1 MCX7-NC-01 EU power cord (CEE 7/7) 1 MCX7-VI-01 Video Interface: GbE TSoIP, SMPTE-2022 DEC (req. MCX7-VP-01 or MCX7-VP-02) 1 MCX7-OU-00 Modulator Output Interface, L-Band with switchable 10 MHz output: L-band 950 MHz to 2150 MHz. SMA (F) 50 Ohm 1 MCX7-ML-01 One Modulator License. Requires Modulator Standard and Coding, and Baud Rate licenses 1 MCX7-SC-03 1x DVB-S/S2/S2X Q/8PSK Modulator Standard and Coding license (includes multistream support) 1 MCX7-SR-02 1x Modulation Symbol Rate up to 15Mbaud. Modulator Maximum Symbol Rate license 1 MCX7-IR-00 Internal Reference Clock, Standard 10MHz: standard stability +/- 2000 ppb over 0 to 700 C. Ageing: +/- 1000 ppb/year 1 MCX7-HC-01 Softcopy documentation on CD 1
