Sony PCS-VCS80 HD multipoint connection unit
HD multipoint connection unit that complies with the H.323 protocol
The PCS-VCS80 is an HD Multipoint Connection Unit allowing easy expansion for videoconferences of up to 500 sites in HD quality video. It allows for multiple screen layout, with up to 16 splits and features continuous presence mode with voice activated switching. The unit supports mixed HD/SD environments. The package is configured with 80 licences.
Key Features
- · Up to 80 licenses
- · Expand videoconferences to 500 sites
- · Supports both HD and SD
- · Multiple screen layout
- · Complies with H.323 protocol
SPECIFICATION Video | |
Communication protocol | H.323 (ITU-T) |
Video codec format | H.261, H.263, H.264 |
Video resolution | 1080i (full screen Video Switch only), 720p, W432p, WCIF, 4CIF, CIF, QCIF |
Video aspect ratio | 4:3 or 16:9 |
H.239 content sharing | Codec - H.263, Resolution - XGA |
Video mode | Full screen (Video Switching mode), Split screen (CPn mode) max. 16 split screen display, Highlight speaker and display terminal name |
Video switching mode | Voice switch, Time switch, Manual switch (Chairman, Selected user) |
Audio | |
Audio mixing | Audio mix of 5 loudest speakers as default, AGC (Automatic Gain Control) |
Meeting type | |
Normal meeting | All users have equal authority of speaker start/stop, etc. |
Chairman control meeting | Chairman has authority of speaker start/stop, changing display layout, etc. |
Access | |
Access method to meeting | Calling out from endpoint (H.323 alias, E.164 number), Calling out endpoint from MCU, Leaving by user operation, Leaving by administrator's or chairman's operation |
Access control | Setting access control for each meetings, Limit by H.323 alias, E.164 number, IP address, Setting for maximum connected users |
Bandwidth | |
Bandwidth Limitation | Max. bandwidth for each meeting and each user, Max. total bandwidth setting |
Max. Bandwidth control method (Static) | New endpoint cannot enter when it reaches max. bandwidth |
Max. Bandwidth control method (Dynamic) | New endpoint can enter when it reaches max. bandwidth, bandwidth is separate by all endpoints |
Meeting scheduling | |
Scheduling mode | Always activate, Scheduled (one time, everyday, every week, every month), Calling out from MCU at reserved starting time |
Number of connected site |
|
Single screen | Max. 500 endpoints |
HD CP4 conference | Max. 250 (768kbps), Max. 200 (1.5Mbps) |
SD CP4 conference | Max. 400 (384kbps) |
General | |
Number of license | 20 |
Support Pack | No (“Support Pack” is an after-sales service package. For details, please contact your nearest Sony office or authorized dealer.) |
Administrative operation | VC Online web-based central management |
Languages | Japanese, English |
Meeting reservation system | Web-based meeting reservation function |
Shared phone book | Embedded shared phone book server of SONY PCS series |
Firmware update | Embedded firmware update function of SONY PCS-XG80, PCS-XG55 |
