Sony LMD-A240 24" LCD Production Monitor
The Sony LMD-A240 24" LCD Production Monitor is a portable, 1920 x 1200 resolution monitor for on set, studio, and broadcast use. The monitor features an IPS LCD display with wide 178° horizontal and vertical viewing angles, and it provides 3G/HD/SD-SDI, HDMI, and composite inputs that support NTSC/PAL, 720p, 1080i, and 1080p input signals with frame rates from 24p to 60p.
Specifications
Display
Number of Displays | 1 |
Panel Type | IPS-Type LCD |
Display Size | 24.06" / 61.1 cm |
Active Area | 20.41 x 12.76" / 51.84 x 32.40 cm |
Screen Resolution | 1920 x 1200 |
Aspect Ratio | 16:10 |
Viewing Angle | Horizontal: 178° (89/89) |
Pixels Per Inch (ppi) | 94 ppi |
Image Controls | Color Temperature Selection, Focus Peaking, Screen Markers, Waveform |
I/O
Video | 2 x BNC (3G-SDI) Output |
Audio | 1 x 3.5 mm Input |
Built-In Speaker | 1 x 1 W |
Power | 1 x 4-Pin XLR Input |
Other I/O | 1 x Parallel (8P8C) |
Card Slot | None |
Format Support
Video Format | SDI (10-Bit 4:4:4 RGB, YCC) |
PC Resolutions | 1680 x 1050 |
Power
AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 0.5 to 0.4 A |
DC Input Power | 12 to 17 VDC |
Battery Type | None |
Power Consumption | 51 W (Maximum) |
Mounting
Mounting-Hole Pattern | 100 x 100 mm |
Environmental
Operating Humidity | 30 to 85% |
Operating Temperature | 32 to 95°F / 0 to 35°C |
Storage Humidity | 0 to 90% |
Storage Temperature | -4 to 140°F / -20 to 60°C |
General
Dimensions (W x H x D) | 22.3 x 15.7 x 3.1" / 56.64 x 39.88 x 7.87 cm |
Weight | 16.75 lb / 7.6 kg |
Warranty Length | Limited 3-Year Warranty |
Packaging Info
Package Weight | 20.75 lb |
Box Dimensions (LxWxH) | 25.8 x 21 x 10.2" |
