This extremely robust and waterproof digital detector array (DDA) has been specially developed for maximum portability and the harsh conditions of industrial radiography.
$89.06
| Active area | 233 mm x 291 mm (9.2" x 11.5") |
| Dimensions (H x W x D) | 368 mm x 327 mm x 21.5 mm / 330 mm x 327 mm x 21.5 mm (without handle) |
| Weight | 3.2 kg (7 lbs) |
| Number of pixels | 3072 x 3840 |
| Exposure time | 500 ms to 180 s |
| Image transfer time (wired/wireless) | 2/4 s |
| Max. energy | 250 kV (for long life in typical applications), Isotopes (higher energies possible) |
| Pixel pitch | 76 μm |
| Scintillator | GOS |
| ADC | 16-bit |
| Interface | Gigabit Ethernet, WLAN: 2.4 GHz (802.11abgn) / 5 GHz (802.11n, 2x2 MIMO) |
| Battery | Lithium-ion (7.4 V, 29.6 Wh) |
| Operating conditions | 0 to 45°C (32 to 113°F), 30 to 85 % humidity |
| Protection level | IP67 (dust-tight and waterproof) |
| Housing | Aluminum frame, carbon-fiber entrance window (150 kg area load) |
| Software | DÜRR NDT D-Tect 9.9 or higher |
| Scope of supply | Detector, 2 battery packs, battery charger, Ethernet data cable |
