AVMATRIX 6CH SDI HDMI/DVI Video Switcher with UVC

Video Input Connectors

4 x BNC (3G-SDI)
2 x HDMI (HDMI 2.0)
2 x DVI-I DL (DVI / VGA)

Input Video Format

SDI
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080i: 50/59.94/60 fps
1080PsF: 23.98/24/25/29.97/30 fps
720p: 23.98/24/25/30/50/59.94/60 fps
576i / 625 lines: 50 fps
480i / 525 lines: 59.94 fps
HDMI
UHD 4K: 30/50/60 fps
DCI 2K: 30/50/60 fps
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080i: 50/59.94/60 fps
720p: 23.98/24/25/29.97/30/50/59.94/60 fps
576p: 50 fps
576i / 625 lines: 50 fps

Audio Input Connectors

2 x 3-Pin XLR Analog
2 x RCA Analog

Video Output Connectors

2 x BNC (3G-SDI) (Program)
2 x HDMI (Program)
1 x USB Type-C (Program)

Output Video Format

HDMI / SDI / USB Type-C
1080p: 24/25/30/50/60 fps

Audio Output Connectors

2 x RCA Analog
1 x 1/8" / 3.5 mm TRS

Multiview Output

8-Way Multiview viaSDI
8-Way Multiview viaHDMI

Other I/O

2 x USB Type-A Input
1 x RJ45 LAN Input
1 x DE-9/DB-9 RS-422
1 x DE-15/DB-15 Tally

Video Standard Compliance

SMPTE 259M/292M/424M

OS Compatibility

Windows 7
Windows 8
Windows 10
macOS
Linux

Power Connector

1 x Barrel (12 VDC at 1.8 A) Input

Power Consumption

22 W

Weight

6.6 lb / 3 kg
