Sony NXL-FR316 - Signal Processing Unit
Non-returnable
$8,000.00
Tags:
The NXL-FR316 is a 3RU rack mountable frame capable of holding up to 16 option boards. With two power supplies to provide redundancy, the unit is ideal for interconnecting SDI equipment with IP-based infrastructure.
Product Details
SPECIFICATION
Power supply
AC 100 V to 240 V +/–10% 50/60 Hz, dual
Power consumption
800 W
Dimensions
440 x 132 x 440 mm (17 3/8 × 5 1/4 × 17 3/8 in.) (W × H × D)
Mass
Approx. 12 kg (30 lb. 14 oz.)
Temperature ranges
Operation guaranteed temperature: 5 °C to 40 °C (41 °F to 104 °F)
Performance guaranteed temperature: 10 °C to 35 °C (50 °F to 95 °F)
Storage temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Performance guaranteed temperature: 10 °C to 35 °C (50 °F to 95 °F)
Storage temperature: –20 °C to +60 °C (–4 °F to +140 °F)
I/O specifications - REFERENCE IN
Connector
BNC type (2), loop through 75 Ω
Number of lines
1 (loop through)
Signal formats
HD tri-level sync signal, black burst signal, SYNC signal
I/O specifications - STATUS OUT
Connector
D-sub 15-pin (female)
Signal formats
Open collector
I/O specifications - NETWORK
Connector
RJ-45
Number of lines
1
Signal formats
Ethernet 100Base-TX compliant
I/O specifications - AUX-IN
Connector
BNC type (1)
Supplied accessories
Supplied accessories
Operation manual (1)
Optional accessories
Optional accessories
RMM-10 rack mount bracket
Power cord (Service Parts No.: 1-557-377-11 (USA, Canada), 1-782-929-22 (EU))
Power cord (Service Parts No.: 1-557-377-11 (USA, Canada), 1-782-929-22 (EU))
