Canon EF 24-105mm f/4L IS II USM Lens

Lens Mount

Canon EF

Lens Communication

Yes, with Autofocus Support

Sensor Resolution

Actual: 9.84 Megapixel (4206 x 2340)
Effective: 8.85 Megapixel (4096 x 2160)

Sensor Type

24.6 x 13.8 mm (Super35) CMOS

Pixel Pitch

6.4 µm

Built-In ND Filter

Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters

Shutter Type

Electronic Rolling Shutter

ISO Sensitivity

160 to 25,600 (Extended: 100 to 102,400)

Gain

-2 to 42 dB (Native)
-6 to 54 dB (Expanded)

Raw Recording

Cinema RAW Light 10-Bit
4096 x 2160 at 50/59.94 fps [1 Gb/s]
Cinema RAW Light 12-Bit
4096 x 2160 at 23.98/24.00/25/29.97 fps [1 Gb/s]

Recording Modes

MP4 4:2:0 8-Bit
3840 x 2160 at 24.00p/29.97p/59.94p [150 MB/s]
1920 x 1080 at 29.97p/59.94p/119.88p [35 MB/s]

Variable Frame Rates

Up to 119.88 fps

Built-In Microphone Type

Mono

Audio Recording

4-Channel 16-Bit 48 kHz

IP Streaming

None

Video I/O

1 x BNC (SDI) Output
1 x HDMI (HDMI 2.0) Output

Audio I/O

2 x XLR 3-Pin Microphone (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm TRS Stereo Microphone Input
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output

Power I/O

1 x LEMO 4-Pin Input

Other I/O

1 x 2.5 mm Sub-Mini (LANC) Control Input
1 x RJ45 (LAN)

Wireless

None

Size

4.0"

Resolution

1,230,000 Dot

Display Type

Included External Touchscreen LCD

Type

Built-In Electronic

Size

0.46"

Resolution

1,770,000 Dot

Battery Type

Canon BP-A Series

Accessory Mount

1 x 1/4"-20 Female
1 x Cold Shoe Mount

Dimensions (W x H x D)

5.7 x 6 x 7" / 14.48 x 15.24 x 17.78 cm (Without Grip)
7 x 6 x 8" / 17.78 x 15.24 x 20.32 cm (With Grip)

Weight

3.2 lb / 1.5 kg
