Atomos Sumo 19" HDR/High Brightness Monitor Recorder/Switcher

Panel Type

IPS-Type LCD

Display Size

19.00" / 48.0 cm

Screen Resolution

1920 x 1080

Aspect Ratio

16:9

Touchscreen

Yes

Maximum Brightness

1200 cd/m²

Bit Depth / Color Support

8-Bit+FRC (1.07 Billion Colors)

Real-Time LUT Monitoring

SDR

Video

1 x HDMI Type A (HDMI 2.0) Output
1 x BNC (12G-SDI) Output
1 x HDMI Type A (HDMI 2.0) Input
3 x BNC (3G-SDI) Input
1 x BNC (12G-SDI) Input

Embedded Audio

HDMI: 8-Channel
SDI: 12-Channel

Audio

2 x XLR Input
1 x 1/8" / 3.5 mm Headphone Output

Built-In Speaker

None

Power

1 x 4-Pin XLR Input

Other I/O

1 x LANC (2.5 mm)

Card Slot

None

Video Format

SDI (8/10-Bit 4:2:2)
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50
HDMI (8/10-Bit 4:2:2)
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50

Video Signal Conversion

HDMI to SDI
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50
SDI to HDMI
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50

Pulldown Conversion

2:2, 3:2

Camera Trigger

SDI, HDMI

Encoding Formats

4096 x 2160
ProRes Raw, Raw HQ, 422, LT, HQ at up to 60 fps
DNxHR HQ, HQX, SQ, LB at up to 60 fps
CinemaDNG at up to 30 fps
3840 x 2160
ProRes Raw, Raw HQ, 422, LT, HQ at up to 60 fps
DNxHR HQ, HQX, SQ, LB at up to 60 fps
CinemaDNG at up to 30 fps
2048 x 1080
ProRes Raw, Raw HQ, 422, LT, HQ at up to 240 fps
DNxHR HQ, HQX, SQ, LB at up to 240 fps
CinemaDNG at up to 120 fps
1920 x 1080
ProRes Raw, Raw HQ, 422, LT, HQ at up to 240 fps
DNxHR HQ, HQX, SQ, LB at up to 240 fps
1280 x 720
ProRes Raw, Raw HQ, 422, LT, HQ at up to 60 fps
DNxHR HQ, HQX, SQ, LB at up to 60 fps
5720 x 3016
ProRes Raw, Raw HQ at up to 30 fps

Recording Media

1 x 2.5" SSD (SATA III)

Phantom Power

+48 V

DC Input Power

VDC

Battery Type

None

Power Consumption

75 W

Mounting

10 x 1/4"-20 Female
5 x 3/8"-16 Female

Dimensions

19.8 x 12.2 x 2.5" / 50.4 x 31 x 6.3 cm
19.8 x 13 x 7.1" / 50.4 x 33 x 18 cm, Including Stand

Weight

12.3 lb / 5.6 kg
13.7 lb / 6.2 kg, Including Stand

Package Weight

18.3 lb

Box Dimensions (LxWxH)

23 x 15.1 x 7"
