DATAVIDEO VP-445 - HD/SD-SDI Distribution Amplifier

Inputs

6 x HDMI (HDCP version 1.4)
4 x 15-pin HD VGA
2 x RCA Composite Video
12 x Unbalanced stereo audio on terminal blocks
2 x 1/4" (6.3 mm) for Mic (with selectable 48 V phantom power)

Outputs

2 x HDMI (HDCP version 1.4)
1 x S/PDIF, RCA
1 x Balanced stereo audio on a 5-pin terminal block connector

Bandwidth

Up to 1080p, UXGA

Switching Time

2 to 3 seconds between inputs

Video Latency

Less than 2 frames

Output Native Resolutions

At 60 Hz
640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1360 x 768, 1280 x 720, 1280 x 800, 1280 x 1024, 1440 x 900, 1400 x 1050, 1680 x 1050, 1600 x 1200, 1920 x 1080, 1920 x 1200, 480p, 720p, 1080i, 1080p

At 50 Hz
576p, 720p, 1080i, 1080p

Controls

HDMI 1 to HDMI 6, PC 1 to PC 4 and CV 1 to CV 2 input selector buttons
Freeze, mute buttons
Menu and navigation buttons, reset to XGA/1080p and lock buttons, RS232, IR, Ethernet (OSD and Web pages)

Power Supply

100 to 240 VAC

Power Consumption

30 W maximum

Operating Temperature

32 to 104°F (0 to 40°C)

Storage Temperature

40 to 158°F (40 to 70°C)

Relative Humidity

10 to 90%, non-condensing

Dimensions

19 x 7.2 x 1.7" (43.6 x 18.3 x 4.36 cm)

Weight

Package Weight

6 lb

Box Dimensions (LxWxH)

21.6 x 11 x 4.2"
