RTS AP-1000-PS1
$193.76
The AP-1000 can be mounted in a variety of methods from wall mounting, handrail, poles and microphone
stands (ordered separately). The AP-1000 provides radio coverage for multiple beltpacks. The coverage area varies
according to the environment and placement of the AP-1000. AP - AC/DC power supply, optional in case no POE+ power available
Product Details
The solid design of the RTS Nomad Wireless Intercom System is matched by the strength and flexibility of the
communication system it supports. Integrating effortlessly with digital wired and legacy analog systems, Nomad
redefines team coordination by wirelessly providing 10 channels of encrypted glitch-free audio and control to
intercom users wherever they may roam.
General
AP-1000 Access Point
Audio BV32 wideband audio
Max. beltpacks per
AP-1000
10
Max. access points in a
system
120
Ethernet type 100BASE-T or GigE
Protocols / standards OMNEO
ST-2110/ST2022-7
DECT
Ethernet cabling required CAT-5e or better
Input voltage (VDC)
DC Power supply +12 VDC, 4-pin XLR input (optional)
DC Battery 14.2 VDC, external battery, via 4-pin XLR input
(optional)
PoE Class 3 device (compatible with PoE, PoE+, and
PoE++)
Power consumption 8.5 W, typical
LED indicators 4 (power, fault, connectivity, location)
NOMAD Wireless Intercom - AP-1000 2 | 3
Environmental
AP-1000 Access point
Operating temperature (°F) -4 °F – 113 °F
Operating temperature (°C) -20 °C – 45 °C
Operating relative humidity, non-condensing
(%)
10% - 90%
Storage temperature (°F) -4 °F – 158 °F
Storage temperature (°C) -20 °C – 70 °C
Dimensions (H x W x D) (in) 9.02 in x 7.60 in x 3.00 in (with
bracket)
9.02 in x 7.60 in x 2.64 in (w/out
bracket)
Dimensions (H x W x D) (mm) 229 mm x 194 mm x 76 mm (with
bracket)
229 mm x 194 mm x 67 mm (w/out
bracket)
Weight (lb) 4.72 lb (with bracket)
4.14 lb (w/out bracket)
Weight (kg) 2.14 kg (with bracket)
1.88 kg (w/out bracket)
Ingress Protection (IP) IP-65
Connections
AP-1000 Access Point
Ethernet connectors 2 x EtherCON RJ-45 jacks
Power connector 1 x 4-pin XLR-F Jack
(accepts power supply or battery supply)
Optical connector 2 x SFP
GPO connector 2 x GPO relay ports
DECT Communications
AP-1000 Access Point
RF frequency range (MHz) 1,920 MHz - 1,930 MHz (US, Canada)
1,880 MHz - 1,900 MHz (EU =
Europe, Asia, Australia)
1,894 MHz - 1,906 MHz (Japan)
1,910 MHz - 1,930 MHz (Mexico,
South America)
Frequency selection Automatic via DCS (Dynamic Channel
Selection)
Modulation DBPSK
Antennas Dual, internal dipole antennas
AP-1000 Access Point
High Difficulty DECT RF environments
Next generation DECT channel compensation
Maximum peak RF output power
(mW) (dBm)
100 mW (20 dBm) (US, Canada,
Malaysia)
250 mW (24 dBm)(Europe, Mexico,
South America, Japan)
Average power (US, Canada, Malaysia)
(dependent on the number of belt
packs)
4 mW - 42 mW
Average power (Europe, Mexico,
South America, Japan)
(dependent on the number of belt
packs)
10 mW - 105 mW
Bluetooth Low Energy Communications
AP-1000 Access Point
BLE frequency range 2400 - 2483.5 MHz
Communication protocol BLE 5.3 (Bluetooth Low Energy)
Modulation GFSK
Antenna Internal ¼-wave
Maximum output power 1 mW
