Aja OG-FIDO-T-12G-S 1-Channel 12G-SDI to Single Mode ST Fiber Transmitter, DashBoard Support

Video Formats

270 Mbps - 12 Gbps, format agnostic

Video Input Digital

1-channel 12G-SDI BNC connector, SMPTE 259/292/424/2081/2082

Video Output Digital

1-channel 12G-SDI reclocked, loop out, BNC connector, SMPTE 259/292/424/2081/2082

1-channel 12G-SDI Single Mode ST Fiber connector, SMPTE 297/259/292/424/2081/2082

Nominal Wavelength: 1260 nm (min), 1310 nm (typ), 1360 nm (max)

Optical Power: -5 dBm (min), 2 dBm (max)

Extinction Ratio: 3.5 (min)

Reclocking

270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.967 Gbps, 2.970 Gbps, 5.934 Gbps, 5.940 Gbps, 11.868 Gbps, 11.880 Gbps - Auto Select

All other rates are passed through and not reclocked

User Interface

openGear DashBoard network control software via Windows, macOS, or Linux

Size

openGear standard form factor, front slot and rear card.

Two slots required for each card.

Weight

0.5 lb (0.3 kg)

Power

openGear frame compatible, 3.0 watts max per card

Environment

Safe Operating Temperature: 0 to 40 C (32 to 104 F)

Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)

Operating Relative Humidity: 10-90% noncondensing

Operating Altitude: <3,000 meters (<10,000 feet)
