Blackmagic Design ATEM Television Studio 4K8
$4,595.00
Tags:
The new ATEM Television Studio 4K8 is a professional live production switcher built into a broadcast control panel so it can be used for high end work while being extremely portable.
Product Details
SPECIFICATION
Number of Mix Effects Rows
1
Direct Cross Points
10
Shifted Cross Points
20
Crosspoint Button Type
Tri-Color LED
Crosspoint Label
6 rows 24 character LCD
Preview Transition
1
Source Select Bus
1
Dedicated Macro Buttons
10 plus shift 10
Transition Type Buttons
5
Transition Rate
Set via system LCD menu display
Key Buttons
8
AUX Buttons
12
Fader Bar
1
Record Buttons
2
Stream Buttons
2
DSK Transition Selectors
6
Fade to Black Buttons
1
System LCD Displays
1
Numeric Keypad
1
3 Axis Joystick
1
Upstream Keyers
4
Downstream Keyers
2
Advanced Chroma Keyers
4
SuperSource
1
DVEs
2
Linear/Luma Keyers
7
Transition Keyer (Stinger/DVE)
1 Stinger, 1 DVE.
Total Number of Layers
8
Pattern Generators
7
Color Generators
2
Control Panel
Integrated panel with full control of switching and settings.
Routable Windows
16
Windows Source Labels
Yes
Tally
Red for program and green for preview indication.
Talkback Support
Yes
Mix Minus Support
Yes
Streaming
Direct Streaming
Supports direct live streaming using Real Time Messaging Protocol (RTMP) over ethernet or a shared internet connection over USB‑C.
Recording
Direct Recording Video and Audio
Direct recording to optional internal M.2 flash memory or to external media via USB-C expansion ports.
Video Recording
Program recorded as a H.264 .mp4 file at the streaming quality setting and at the ATEM video standard with AAC audio.
Media Format
Supports media formatted ExFAT (Windows/Mac). APFS or HFS+ (Mac).
Multi View Monitoring
Multi View Monitoring
1 x multi view via SDI and HDMI configurable to 16, 13, 10, 7 or 4 up views. Includes monitoring of Program, Preview, Inputs, Media Players, DSKs, SuperSource, Clean Feed with optional labels and audio meters.
Multi View Video Standard
HD or Ultra HD
Display Minimum Resolution
1366 x 768
