Blackmagic Design Studio Camera 4K Plus

Sensor Resolution

Not Specified by Manufacturer

ISO Sensitivity

100 to 25,600

Gain

0 to 18 dB

Signal-to-Noise Ratio

63 dB

Lens Mount

Micro Four Thirds

Built-In ND Filter

None

Built-In Microphone Type

Stereo

Broadcast System Compatibility

NTSC, PAL

CCU Interface

None

Video Connectors

1 x HDMI Output

Audio Connectors

1 x 1/8" / 3.5 mm Stereo Mic Level Input
1 x 1/8" / 3.5 mm TRRS Headphone/Microphone Input/Output

Other I/O

2 x USB Type-C USB 3.1 Gen 1 Data, Video Input/Output

Recording Modes

DNxHD/ProRes:
3840 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fps
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

Raw Recording

Blackmagic RAW:
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps (26 to 190 Mb/s)

Audio Recording

Raw: 2-Channel 24-Bit 48 kHz LPCM Audio

Display Type

Fixed Touchscreen LCD

Size

7"

Resolution

1920 x 1200

Power Connectors

1 x Barrel (12 VDC) Input

Power Consumption

>46 W

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 113°F / -20 to 45°C

Operating Humidity

0 to 90%

Accessory Mount

2 x 1/4"-20 Female

Tripod Mount

3/8"-16 Female

Dimensions

10.77 x 6.68 x 6.59" / 27.36 x 16.97 x 16.74 cm (Without Protrusions)

Weight
