The ME 104B modular mini-microphone capsule fulfills professional demands for sound quality and rugged handling, and is suitable for all areas of live work where a small and unobtrusive microphone is needed for vocal and speech applications.

The ME 104B modular mini-microphone capsule fulfills professional demands for sound quality and rugged handling, and is suitable for all areas of live work where a small and unobtrusive microphone is needed for vocal and speech applications.
SPECIFICATION
Dimensions
d 6 x 12 mm
Frequency response (Microphone)
100.....20000 Hz
Weight
80 g
Pick-up pattern
cardioid
Sensitivity in free field, no load (1kHz)
8 mV/Pa +- 2,5 dB
Nominal impedance
1000 Ω
Min. terminating impedance
4700 Ω
Equivalent noise level
30 dB
Equivalent noise level weighted as per CCIR
38 dB
Maximum sound pressure level (passive)
133 dB (K = 1%)
Current consumption
ca. 250 µA
Sensitivity in free field
8 mV/Pa +- 2,5 dB
Weight w/o cable
1 g
