Panasonic AG-UX90 UHD 4K Professional Camcorder

Image Sensor

1-Chip 1" MOS Sensor

Sensor Resolution

3840 x 2160 (8.59 MP)

Effective Sensor Resolution

3840 x 2160 (8.59 MP)

Gain

0 to 30 dB (Native)

Minimum Illumination

1.3 Lux at 1/30 Shutter Speed

White Balance Range

2000 to 15,000K

Focal Length

8.8 to 132mm

35mm Equivalent Focal Length

24.5 to 367.5mm

Optical Zoom Ratio

15x

Max Digital Zoom

10x

Maximum Aperture

f/2.8

Minimum Aperture

f/4.5

Minimum Focusing Distance

Not Specified by Manufacturer

Filter Size

67 mm

Control Rings

Focus
Zoom
Iris

Image Stabilization

Optical

Focus Control

Autofocus
Manual Focus

Shutter Speed

1/60 to 1/8000 sec

Scan Rate Adjustable

Yes

Built-In ND Filter

None

Built-In Microphone Type

Stereo

Media/Memory Card Slot

Dual Slot: SD/SDHC/SDXC (UHS-I) [Class 10/U1/V10 or Faster Recommended]

Recording Modes

MP4 4:2:0 8-Bit:
3840 x 2160p at 23.98/29.97 fps (100 Mb/s)
1920 x 1080p at 23.98/29.97/59.94 fps (50 to 200 Mb/s)
AVCHD 4:2:0 8-Bit:
1920 x 1080p at 23.98/59.94 fps (21 to 25 Mb/s)
1920 x 1080i at 59.94 fps (17 to 21 Mb/s)
1440 x 1080i at 59.94 fps (5 Mb/s)
1280 x 720p at 59.94 fps (8 Mb/s)
720 x 480i at 59.94 fps (9 Mb/s)

Variable Frame Rates

1080p: 2 to 60 fps
1080p: 2 to 60 fps

Audio Recording

MP4: 2-Channel 16-Bit 48 kHz LPCM Audio
AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio

Still Image Support

JPEG
8.3 MP (3840 x 2160)
2 MP (1920 x 1080)
.9 MP (1280 x 720)

IP Streaming

None

Video Connectors

1 x RCA (Composite) Output
1 x HDMI Output

Audio Connectors

2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm Stereo Headphone Output

Other I/O

1 x 2.5 mm Camera Interface Control Input
1 x 3.5 mm Camera Interface Control Input
1 x USB Type-A Camera Interface Data Output
1 x USB Micro-B Camera Interface Data Input/Output

Display Type

Articulating LCD

Size

3.5"

Resolution

1,150,000 Dot

EVF Display Type

OLED

Screen Size

.24"

EVF Resolution

1,560,000 Dots

Battery Type

Panasonic AG-VBR Series

Power Connectors

1 x Proprietary (7.2 to 12 VDC) Input

Power Consumption

12.2 W

Operating Temperature

32 to 104°F / 0 to 40°C

Operating Humidity

10 to 80%

Accessory Mount

1 x Cold Shoe Mount

Tripod Mount

1/4"-20 Female

Dimensions

6.65 x 7.68 x 13.39" / 169 x 195 x 340 mm (Without Protrusions)

Weight

4.2 lb / 1.91 kg

Warranty Length

Limited 1-Year Warranty

Package Weight

9.8 lb

Box Dimensions (LxWxH)

18.4 x 13.1 x 11.1"
