Autoscript EVO-IPS15 on-camera package with carbon fibre hood c/w WP-IPS

Specifications

Display Size

15"

Aspect Ratio

4:3

Brightness

450 nits

Resolution

1024 x 768

Contrast Ratio

800:1

Script Inputs

LAN only

Power Input

4-pin XLR, 12VDC +/- 5%

Power Consumption

20.4W Max

Viewing Angle (Horizontal/Vertical)

160 deg. / 140 deg.

Mounting

On-camera system with Intelligent Prompting mounting system, backplate, carbon fibre hood and glass

Software ApplicationJump to...

Minimum System Requirements

Operating System: Windows 7 or later
32 Bit and 64 Bit OS supported
Hard Drive: 1GB of free disk space
RAM: 4GB
Processor: i3
Graphics: Graphics card supporting OpenGL 3 for smooth preview/VGA prompting

Application

Connects automatically to Intelligent Prompting devices on the connected IP network (only one controller will connect at any time)
In-screen real time scroll preview
Simple customizable user interface: resizable windows, color selection, content tile position, content tile pin to sidebar, tabbed windows
Script edits during live prompting
Multi language support
Word & RTF Import and Export
Graphical scroll control

Run Order

Options: Add story, remove story, cloak story, drop story, scroll to prompter, track live story
Available run order preview
Drag and drop story

Story Editor

Options: Font type, font size, font format, font color, background color, spell check, cut & paste
Script matches prompt mode to indicate prompt output
Follow prompter
Font resize slider

Prompter Preview

Super smooth scroll
Options: On-screen message, invert colors, blank screen
Presenter preferences

Device Management

Status: Add manual, add discovered, monitoring
Configuration of EVO-IPS: Brightness, contrast, image flip
Remote program of scroll control function buttons
Remote software and firmware updates

Compatibility

HC-IP desktop scroll control (included), FC-IP foot control (not included), Wireless hand control (not included)
EVO-IPS monitors, EVO-IP monitors, including EPIC-IP systems (no monitor included, no XBox-IP required)
XBox-IP scroll engine (not included, produces dual HD-SDI output)

Desktop Hand ControlJump to...

Standard Function Buttons

Next (page/bookmark/ snapshot)
Previous (page/bookmark/ snapshot)
Top of script

Programmable Function Buttons

2x Illuminated function buttons programmed within WinPlus-IP
Color options: RGB, White standard (User definable)

Status Display

Illuminated multi-color window shows device network status and operational mode

Power

3W Max power consumption
Powered over Ethernet (PoE)
Requires 3rd party PoE injector or XBox-IP (not included)

Connector

1x RJ45

GeneralJump to...

Dimensions

Monitor: 400 x 317 x 42mm (15.75 x 12.48 x 1.65")
Desktop Hand Control: 42 x 134 x 230mm (1.65 x 5.28 x 9.06")

Weight

Complete On-Camera System: 10.3kg (22.71 lbs)
Monitor Only: 2.8kg (6.17 lbs)
Desktop Hand Control: 500g (17.64 oz)
