Sony PXW-FS7M2 XDCAM Super 35 Camera System

Image Sensor Size

Super35

Sensor Type

CMOS

Sensor Resolution

Effective: 4096 x 2160

Gain

-3 to 18 dB

Signal-to-Noise Ratio

57 dB

Lens Mount

Sony E-Mount

Shutter Speed

1/3 to 1/9000 sec

Built-In ND Filter

Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters

Recording Media

2 x XQD Card Slots
1 x SD Card Slot

Variable Frame Rates

1 to 180 fps

Recording Modes

XAVC-I 4:2:2 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (240 to 600 MB/s)
XAVC-L 4:2:0 8-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (100 to 150 MB/s)

Gamma Curve

Sony S-Log 3

Audio Recording

4-Channel 24-Bit 48 kHz

Raw Output

SDI/BNC:
4096 x 2160 12-Bit
2048 x 1920 12-Bit

Video Connectors

2 x BNC (3G-SDI) Output
1 x HDMI (HDMI 2.0) Output

Other I/O

1 x 2.5 mm LANC Control Input
1 x USB Mini-B Data Input/Output
1 x 2.5 mm LANC Control Input

Display Type

Included External LCD

Size

3.5"

Resolution

1,560,000 Dot

EVF

Included

Battery Type

Sony BP-U Series

Power Connectors

1 x Barrel Input

Power Consumption

19 W

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 140°F / -20 to 60°C

Accessory Mount

1 x Multi-Interface Shoe
1 x 1/4"-20 Female

Dimensions

6.14 x 9.41 x 9.72" / 156 x 239 x 247 mm

Weight

9.9 lb / 4.4 kg

Package Weight

Box Dimensions (LxWxH)

15.7 x 13.5 x 12.5"
