Blackmagic Design ATEM Micro Camera Panel
ngshop.co.
0
Currency
Blackmagic Design ATEM Micro Camera Panel
Blackmagic Design ATEM Micro Camera Panel

Blackmagic Design ATEM Micro Camera Panel

$595.00
The ATEM Micro Panel is a fantastic hardware panel for physical switching while using ATEM Software Control. It features the same professional panel design as ATEM Advanced Panels with high end backlit buttons and a low profile manual transition fader that keeps the ATEM Micro Panel incredibly portable
Quantity
Add to Cart
Product Details

About ATEMMicro Camera Panel

ATEM Micro Camera Panel lets you control your cameras with a high end broadcast CCU style controller! Buttons along the side let you select between 8 cameras, plus you can check which cameras are on-air before adjusting them! The design features a smooth machined metal control for adjusting iris and pedestal. You can also control the camera’s shutter speed, white balance, RGB gain and more.

Technical Specifications

Print Tech Specs

Connections

Computer Interface

USB Type‑C.

Bluetooth

Bluetooth 5.1 LE

Software Updates

1 x USB‑C for firmware updates.

ATEM Micro Camera Panel

Product Specifics

Camera Selection buttons

8 x NKK buttons.

Assignable via setup utility.

Camera Number Display

Green off air, red on air.

Setup

White and black balance setup.

Flare via modifier key.

3 Axis Joystick

1

Preview Button

1

Iris Control

Auto Iris On, Coarse control.

Iris Range

CLS f32 to f1.2

Gain Range

-12dB to +32dB

ND Filters

0, 2, 4, 6.

Shutter Range

1/24 to 1/2000

White Balance Range

2500K to 10,000K

Recallable Scenes

5 per camera.

Panel Active

Protects settings.

Software

Software Applications

ATEM Micro Panel controls ATEM Software Control Panel running on the host computer.

Operating Systems

Mac icon

Mac 14.0 Sonoma,
Mac 15.0 Sequoia or later.

Windows Icon

Windows 10 and 11.Windows 11 for ARM

Power Requirements

Power Supply

Internal battery with power switch.

USB-C port for external power supply and battery charging.

Power Usage

4 W max.

Battery Life

Minimum 3 hours.

(under normal use)

Physical Specifications

ATEM Micro Camera Panel

Environmental Specifications

Operating Temperature

5° to 40° C (41° to 104° F)

Storage Temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing

What's Included

ATEM Micro Camera Panel

Welcome wallet with QR code for software download

1 x USB‑C cable

Warranty

1 Year Limited Manufacturer’s Warranty.
