Blackmagic Design Video Assist 5 3G
It features a bright 7", 1920 x 1200 display with 300 cd/m² brightness to help you frame and focus your shots, and it provides 3G-SDI and HDMI inputs for recording the video output from professional and consumer cameras.
Specification
Display
Panel Type | LCD |
Display Size | 5.0" / 12.7 cm |
Aspect Ratio | 16:9 |
Viewing Angle | Horizontal: 135° |
Touchscreen | Yes |
Maximum Brightness | 300 cd/m2 |
Pixels Per Inch (ppi) | 441 ppi |
Color Gamut | 100% Rec. 709 |
Real-Time LUT Monitoring | SDR |
Image Controls | Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Histogram, Image Flip, Picture-in-Picture, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra |
Wi-Fi | None |
I/O
Video | 1 x HDMI Type A Input |
HDCP Support | Yes |
Embedded Audio | HDMI: 8-Channel |
Audio | 1 x 1/8" / 3.5 mm Headphone Output |
Built-In Speaker | 1 |
Power | 1 x Barrel Input |
Format Support
Video Format | SDI (10-Bit 4:2:2 YUV) |
Recording
Pulldown Conversion | None |
Camera Trigger | None |
Pre-Roll Record | None |
Encoding Formats | Up to 1920 x 1080 |
Maximum Audio Tracks | 16 |
Recording Media | 1 x SDXC (UHS-I) |
Metadata Tagging | Yes |
Timecode Support | Yes |
Phantom Power | None |
Power
Battery Type | 2 x L-Series |
Mounting
Mounting | 6 x 1/4"-20 Female |
Environmental
Operating Temperature | 32 to 104°F / 0 to 40°C |
Operating Humidity | 0 to 90% |
Storage Temperature | -4 to 113°F / -20 to 45°C |
General
Material of Construction | Aluminum |
Dimensions | 5.83 x 3.54 x 1.44" / 14.81 x 8.99 x 3.66 cm |
Weight | 14.46 oz / 410 g |
Warranty Length | Limited 1-Year Warranty |
