Sony UTX-B03HR/K42 UWP-D Bodypack Transmitter
The UTX-B03HR body-pack transmitter forms part of a complete UWP-D audio system offering the sound quality of digital audio processing combined with the reliability of analogue FM modulation. It offers wide frequency coverage with up to 72 MHz bandwidth (depending on region) across a wide range of channels, with a choice of models to choose from.
Specification
Oscillator Type: Crystal-controlled PLL Synthesizer
Antenna Type: 1/4 wave length wire
Type of Emission: F3E
Carrier Frequencies: Europe, UAE, South Africa, Australia, Malaysia, Vietnam, New Zealand
- UTX-B03/21: 470.025 MHz to 542.000 MHz (not available in Australia, Malaysia, Vietnam or New Zealand)
- UTX-B03/33: 566.025 MHz to 633.000 MHz (not available in New Zealand)
- UTX-B03/42: 638.025 MHz to 694.000 MHz
RF Power: Americas, Europe, UAE, South Africa, Australia, Malaysia, Vietnam, New Zealand,
China 30mW / 5mW
Input Connector: Sony SMC9-4S (female)
Reference Input Level:
- MIC: -60 dBV (at 0-dB attenuator level)
- LINE: +4 dBu
Audio Attenuator Adjustment Range: 0dB to 27dB (in 3-dB steps): Mic input
Frequency Response: Americas, Europe, UAE, South Africa, Australia, Malaysia, Vietnam, New Zealand Transmission: 23Hz to 18kHz (typical)
Signal-to-Noise Ratio: 96dB (max deviation, A-weighted)
Audio Delay: Approx. 0.35 msec
Pilot Tone Signal: 32 kHz/ 32.382 kHz/ 32.768 kHz
Display: LCD
- Power Requirements:
- DC 3.0 V (with two AA-size alkaline (LR6) batteries)
- DC 5.0V (via USB micro-B)
Battery Operating Time: Americas, Europe, UAE, South Africa Approx. eight hours with Sony's AA-size alkaline (LR6) batteries at 25°C(77°F) at 30-mW
Operating Temperature:
- 0°C to 50°C
- 32°F to 122°F
Storage/Transport Temperature:
- -20°C to +55°C
- -4°F to +131°F
Dimensions: 63 x 82 x 20 mm (excluding the anntenas) (W x H x D)
Mass: Approx. 151 g (including batteries)
