DATAVIDEO SSD Drive for HDR/HRS products, 512GB
Model Number
HDR-70
Video Standard
HD & SD
Video Format
1080p 23.97/24Hz
1080i 50/59.94/60Hz
720p 50/59.94/60Hz
576i 50Hz, 480i 59.94Hz
Supported Video Input Signal
1x SDI
Video Output
1x SDI (Input Loop Thru)
1x HDMI, 1x SDI (Out)
Analog Audio Input
2x Balanced XLR (Stereo pair)
Analog Audio Output
2x Balanced XLR
Embedded Audio
Both In & Out (8-CH on SDI/HDMI)
Storage Medium
2.5" Hard Drive / SSD*, Max capacity 1TB
Multi-channel Recording
1-CH HD only
Estimated Record Time (min per 10GB)
SD: 19 (50Mbps) ~ 70 (8Mbps)
HD: 8 (125Mbps) ~ 62 (10Mbps)
Recording Media
1x 2.5" Removable HDD/ SSD
Storage File System
NTFS
Recorded File Format
MXF OP1A, MOV
Video Recording Bit Rate / Color Sampling
MPEG2 Long GOP HD:
1. 10/ 25Mbps 4:2:0 1440x1080/1280x720,
2. 35/ 50/ 65/ 120Mbps 4:2:2 1920x1080/1280x720,
MPEG2 Long GOP SD:
1. 8Mbps 4:2:0 720x480/720x576 (to be F/W upgrade)
2. 15/ 30/ 50Mbps 4:2:2 720x480/720x576
MPEG2 I-Frame Only HD:
1. 80/ 100/ 125Mbps 4:2:2 1920x1080/1280x720
MPEG2 I-Frame Only SD:
1. 25/ 50Mbps 4:2:2 720x480/720x576
Audio Recording Format
Uncompressed PCM
Sampling rate 48KHz 24bit
Preview Display
---
Time Code In / Out
Yes
External Sync / Genlock
Black Burst & Tri-level with loop thru
External Control
RS-232/422 (Dsub 9pin), GPI (min XLR)
Power Failure Protection
Content saved up to last second before power failure
Chassis
1RU 19” rack-mountable
Dimension (LxWxH)
288 x 481 x 49 mm
Operating Temp. Range
0~40 °C
Power
DC 12V, 2A
What's in the Box
1 x HDR-70 product
1 x AD Switch DC 12V
1 x USB Cable (Y type)
2 x 2.5" Removable HDD Enclosure (HDD Not Included)
10 x M3 X 4 m/m Screws
2 x 2.0 X 6 m/m Screws
2 x HD Label
4 x Label
2 x L type stand
Approved Drives
Crucial MX220 (250GB)
Hitachi 7K320-320 (320GB)
Intel 330 Series (120GB)
Intel 520 Series (120GB)
Kingston Hyper X (240GB)
Kingston Hyper X (128GB)
Samsung 840 EVO (1TB)
Samsung 840 PRO (128GB)
Samsung 850 PRO (256GB)
Sandisk Extreme (120GB)
Sandisk Extreme (240GB)
Sandisk Extreme II (120GB)
Sandisk Extreme II (240GB)
Sandisk X110
Sandisk X300s (512GB)
Silicon Power V30 (120GB)
Transcend SSD320 (120GB)
Transcend SSD370 (512G)
WD WD3200BEKT (320G)
WD WD5000BEKT (500GB)
WD WD5000BPKT (500GB)
WD WD3200LPLX (320GB)
WD WD5000LPLX (500GB)
WD WD7500BPKT (750GB)
