Autoscript EVO-IPS19 on-camera package with carbon fibre hood c/w WP-IPS
The new EVO-IPS is a cost effective IP-only solution for progressive modern studios. The standard bright prompt monitor uses the super slim chassis of the more highly featured EVO-IP, with a depth of just 42mm and a lightweight design that makes the larger 19" monitor the natural choice.
Specifications
Display Size
19"
Aspect Ratio
4:3
Brightness
350 nits
Resolution
1280 x 1024
Contrast Ratio
1000:1
Script Inputs
LAN only
Power Input
4-pin XLR, 12VDC +/- 5%
Power Consumption
30W Max
Viewing Angle (Horizontal/Vertical)
170 deg. / 160 deg.
Software ApplicationJump to...
Minimum System Requirements
Operating System: Windows 7 or later
32 Bit and 64 Bit OS supported
Hard Drive: 1GB of free disk space
RAM: 4GB
Processor: i3
Graphics: Graphics card supporting OpenGL 3 for smooth preview/VGA prompting
Application
Connects automatically to Intelligent Prompting devices on the connected IP network (only one controller will connect at any time)
In-screen real time scroll preview
Simple customizable user interface: resizable windows, color selection, content tile position, content tile pin to sidebar, tabbed windows
Script edits during live prompting
Multi language support
Word & RTF Import and Export
Graphical scroll control
Run Order
Options: Add story, remove story, cloak story, drop story, scroll to prompter, track live story
Available run order preview
Drag and drop story
Story Editor
Options: Font type, font size, font format, font color, background color, spell check, cut & paste
Script matches prompt mode to indicate prompt output
Follow prompter
Font resize slider
Prompter Preview
Super smooth scroll
Options: On-screen message, invert colors, blank screen
Presenter preferences
Device Management
Status: Add manual, add discovered, monitoring
Configuration of EVO-IPS: Brightness, contrast, image flip
Remote program of scroll control function buttons
Remote software and firmware updates
Compatibility
HC-IP desktop scroll control (included), FC-IP foot control (not included), Wireless hand control (not included)
EVO-IPS monitors, EVO-IP monitors, including EPIC-IP systems (no monitor included, no XBox-IP required)
XBox-IP scroll engine (not included, produces dual HD-SDI output)
Desktop Hand ControlJump to...
Standard Function Buttons
Next (page/bookmark/ snapshot)
Previous (page/bookmark/ snapshot)
Top of script
Programmable Function Buttons
2x Illuminated function buttons programmed within WinPlus-IP
Color options: RGB, White standard (User definable)
Status Display
Illuminated multi-color window shows device network status and operational mode
Power
3W Max power consumption
Powered over Ethernet (PoE)
Requires 3rd party PoE injector or XBox-IP (not included)
Connector
1x RJ45
GeneralJump to...
Dimensions
Monitor: 468 x 399 x 42mm (18.43 x 15.71 x 1.65")
Desktop Hand Control: 42 x 134 x 230mm (1.65 x 5.28 x 9.06")
Weight
Complete On-Camera System: 11.5kg (25.35 lbs)
Monitor Only: 4kg (8.82 lbs)
Desktop Hand Control: 500g (17.64 oz)
