DJI Ronin-S Essentials Kit
The DJI Ronin-S is more than just a miniaturized version of the larger Ronin gimbal stabilizers; it represents a scalable ecosystem for integrating DSLR and mirrorless cameras into professional-grade workflows. The single-handed form factor of the Ronin-S lends itself to lighter camera payloads, up to eight pounds.
Specification
Gimbal
Number of Axes | 3-Axis (Pitch, Roll, Yaw) |
Rotation Range | Yaw (Pan): 360° |
Follow Speed | Pan: 360°/s |
Load Capacity | 7.94 lb / 3.6 kg |
Connectivity
Ports | 1 x USB Type-C (Power / Control) Input |
Wireless Frequency | Remote: 2.4 GHz (2.4 - 2.48) |
Wireless Protocol | Bluetooth 4.0 |
Battery
Battery Type | 1 x Built-In |
Capacity (mAh) | 2400 mAh |
Capacity (Wh) | 34.56 Wh |
Battery Runtime | 12 Hours |
Battery Chemistry | Lithium-Ion |
Power
Operating Current | 0.16 A |
Environmental
Operating Temperature | -4 to 113°F / -20 to 45°C |
General
Mounting | 1 x 1/4"-20 Female |
Dimensions | 23.23 x 11.54 x 10.08" / 590 x 293 x 256 mm |
Weight | 4.1 lb / 1.86 kg |
