Sony NXLK-IP40F/1 - SDI-IP Converter Board
ngshop.co.
0
Currency
NXLK-IP40F/1

Sony NXLK-IP40F/1 - SDI-IP Converter Board

Non-returnable
$4,038.46
Tags:
The NXLK-IP40F SDI-IP converter board provides 4x 3G-SDI ports and 2x SFP+ ports for redundancy for network connection. The NXLK-IP40F can convert the signal in a very low latency which enables live production over IP transmission where real-time operation is essential.
Quantity
Add to Cart
Product Details
SPECIFICATION

Power supply
DC 12 V (supplied from NXL-FR318)
Power consumption
2.0 A 24 W (2 slot occupancy)
Dimensions
Main board: 114.5 × 28 × 275.8 mm (4 5/8 × 1 1/8 × 10 7/8 in.)(W × H × D)
Connector board: 131 × 35.2 × 117.25 mm (5 1/4 × 1 7/16 × 4 5/8 in.) (W × H × D)
Mass
Main board: 240 g (8.5 oz.)
Connector board: 160 g (5.6 oz.)
Temperature ranges
Operation guaranteed temperature: 5 °C to 40 °C (41 °F to 104 °F)
Performance guaranteed temperature: 10 °C to 35 °C (50 °F to 95 °F)
Storage temperature: –20 °C to +60 °C (–4 °F to +140 °F)
I/O specifications - SDI
Connector
BNC type 75 Ω
Number of lines
4
Signal formats
SMPTE ST 424, SMPTE ST 292-1
I/O specifications - REF OUT
Connector
DIN 1.0/2.3 75 Ω
Number of lines
1
Signal formats
HD tri-level sync signal, black burst signal (NTSC, PAL), SYNC signal (NTSC, PAL)
I/O specifications - NMI LAN
Connector
SFP+
Number of lines
2
Signal formats
10GBASE-** (dependent on SFP+ transceiver module)
For details on supported SFP+ transceiver modules, contact your local Sony service representative.
Supplied accessories
Supplied accessories
Operation manual (1)
Supported formats
SDI input/output
1920 x 1080 59.94i, LLVC compression or uncompressed
1920 x 1080 50i, LLVC compression or uncompressed
3840 x 2160 59.94p Level-A, 2SI or SQD, LLVC compression
3840 x 2160 50p Level-A, 2SI or SQD, LLVC compression
