AVMatrix PTZ1270 Full HD PTZ Camera with POE and NDI (10x Optical Zoom)
Add a powerful PTZ camera setup with HD video capture to your production with this PTZ1271-20X-NDI Full HD PTZ Camera from AVMatrix. The camera offers precision control and multiple output ports offering up to 1080p video, and it also supports control and streaming over LAN.
Image Sensor
Image Sensor | 1-Chip 1/2.8" CMOS Sensor |
Sensor Resolution | Effective: 2.07 Megapixel |
Signal-to-Noise Ratio | 55 dB |
White Balance | 3000 to 7000K |
Camera
Max Digital Zoom | 10x |
Built-In ND Filter | None |
Lens
Optical Zoom Ratio | 20x |
Focal Length | 5.5 to 110mm |
Maximum Aperture | f/1.6 to 3.5 |
Video Output
Output Formats | SDI, HDMI: 1920 x 1080p |
IP Streaming | RTMP, RTSP, SRT: 1080p |
Recording Modes | Not Specified by Manufacturer |
Control
Presets | 255 |
Move Speed | Pan: 0.1 to 180°/sec |
Movement Range | Pan: 340° (-170 to 170°) |
Supported Control Protocols | Pelco-D |
Interfaces
Video Output Connectors | 1 x BNC (3G-SDI) |
Audio I/O | 1 x 1/8" / 3.5 mm Stereo Line Level Input |
Control Interface | 1 x RJ45 (LAN) |
Power
PoE Support | Yes |
Power Connectors | 1 x Barrel / Coaxial |
Power Consumption | Device: 12 VDC at 1 A (12 W) |
Environmental
Operating Temperature | 14 to 122°F / -10 to 50°C |
Storage Temperature | 14 to 140°F / -10 to 60°C |
Operating Humidity | 20 to 80% (Non-Condensing) |
Storage Humidity | 20 to 95% (Non-Condensing) |
General
Tripod Mounting Thread | 1 x 1/4"-20 Female |
Dimensions | 7.1 x 6.7 x 6.7" / 180.31 x 170 x 170 mm |
Weight | 2.76 lb / 1.25 kg |
Package Weight | 2.26 kg |
